Introduction

Fixed Side Guides provide a modular and flexible solution for conveyor systems, ensuring product stability during transport.

Designed to be adaptable to a wide range of applications, these side guides feature industry-standard UHMW liners that protect delicate product surfaces by preventing marring and reducing friction.

Whether for high-speed manufacturing lines or delicate handling in cleanroom environments, Fixed Side Guides offer reliability and versatility.

Optimal Product Control

Fixed Side Guides are engineered for long-term use with a rugged construction that withstands the demands of daily operations. Their compact design allows for easy integration into existing conveyor setups, while the UHMW liners ensure maximum protection for your products.

Specifications

Features

Benefits

Options

  • Height Bracket Options: Low, Medium, and High brackets available for versatile product support.

    • Bracket Sizes:

    • Low: Size A (13/16"), Size B (1"), Size D (1.75"), Size E (2.125"), Size F (3"), Size G (4")
    • Medium: Size A (13/16"), Size B (1"), Size D (1.75"), Size E (2.125"), Size F (3"), Size G (4")
    • High: Size A (13/16"), Size B (1"), Size D (1.75"), Size E (2.125"), Size F (3"), Size G (4")
  • Liners: Equipped with UHMW liners to minimize frictional drag and protect product surfaces.
  • Material: Constructed from high-grade materials to withstand demanding conditions and ensure a long service life.
  • Preset Width Adjustment: Offers precise control over guide width settings, allowing for quick and easy configuration changes.
    • Modular Design: Easily integrated into conveyor systems with adjustable brackets for various product sizes.
    • UHMW Liners: Industry-standard UHMW liners provide a non-marring surface, reducing product friction and ensuring protection during transport.
    • Multiple Height Bracket Options: Available in low, medium, and high brackets to suit different product heights, providing versatile support.
    • Rugged Construction: Built with high-grade materials for enhanced durability, ensuring reliable performance over extended use.
    • Quick Removal: Designed for fast removal and replacement, minimizing maintenance downtime and allowing for swift reconfiguration.
    • Product Protection: UHMW liners prevent product marring and reduce friction, ideal for delicate items and high-speed operations.
    • Versatile Support: Offers low, medium, and high bracket options, accommodating a wide range of product sizes and applications.
    • Quick Maintenance: Easy removal and preset width adjustments allow for swift changes, reducing downtime and improving efficiency.
    • Long-Lasting Performance: Rugged construction ensures long-term use, reducing the need for frequent replacements.
  • Bracket Height: Choose from low, medium, or high brackets to fit various product requirements.
  • Liner Material: Optional liners are available to suit specific application needs, including higher temperature resistance or added cushioning for delicate items.

    • Key Features

    • Non-marring UHMW liners

    • Modular, flexible design

    • Multiple height bracket options

    • Quick preset width adjustment

    • Rugged and durable for long-term use

    Documentation

    Side Guides Brochure
    Side Guides Technical Drawings
    Specification Details
    Bracket Height Options Low, Medium, High
    Bracket Sizes - Low: Size A (13/16"), Size B (1"), Size D (1.75"), Size E (2.125"), Size F (3"), Size G (4")
    - Medium: Size A (13/16"), Size B (1"), Size D (1.75"), Size E (2.125"), Size F (3"), Size G (4")
    - High: Size A (13/16"), Size B (1"), Size D (1.75"), Size E (2.125"), Size F (3"), Size G (4")
    Liner Material UHMW (Ultra-High-Molecular-Weight Polyethylene)
    Material High-grade construction for enhanced durability
    Width Adjustment Preset width adjustment for rapid configuration
    Quick Removal Tool-free removal and replacement
