Introduction

The Right Angle Gear Motor offers a compact yet powerful solution for a variety of conveyor systems. Designed to fit seamlessly into tight spaces, this gear motor delivers high-torque output, ensuring smooth and efficient operations.

Its robust design allows it to handle higher loads while minimizing maintenance, making it ideal for manufacturing environments that demand reliable and efficient material handling.

Compact and High-Torque Performance

The Right Angle Gear Motor’s compact design optimizes space without compromising performance. Its high-torque output ensures smooth and efficient operations, making it perfect for setups with limited space while providing reliable performance.

Specifications

Features

Benefits

Options

  • Motor Power Options: 90V DC Motor, 115V-1ph-AC, 208V-1ph-AC, 230V-1ph-1PH, 230/460V-3ph-AC
  • Torque Range: 33 to 150 lb-in (3.7 to 17 Nm)
  • Speed Options: 34 to 360 RPM, Fixed Speed, 1.7 to 525 RPM, variable speed
  • Mounting Styles: Flange-mounted,
  • Gearbox Construction: Cast aluminum housing with hardened steel gears for maximum durability filled with synthetic lube and lubed for life. Worm supported on (2) anti-friction bearings within the reducer housing
  • Operating Environment: Suitable for a variety of manufacturing conditions, including washdown environments
  • Warranty: 2-year
    • High Torque in a Compact Design: Provides maximum torque output without taking up excessive space, perfect for low-profile conveyor applications.
    • Sealed Gearbox: Comes with a maintenance-free, sealed gearbox to protect internal components and extend the motor’s operational life.
    • Versatile Mounting Options: Offers various mounting configurations to suit different conveyor setups, enhancing flexibility in applications.
    • Durable Construction: Built with cast aluminum housing and hardened steel gears for durability and extended service life.
    • Adjustable Speed Control: Variable speed control allows precise adjustments to suit different operational needs.
  • Space-Saving Design: Ideal for tight conveyor setups, the right-angle configuration optimizes available space while providing high-torque performance.
  • Maintenance-Free Operation: The sealed gearbox design is filled with a synthetic lube, eliminating the need for regular maintenance, reducing downtime and labor costs.
  • Versatile Applications: Suitable for a wide range of conveyor systems, including precision indexing, parts handling, and product inspection.
  • Improved System Longevity: Durable construction and high-quality components ensure long-lasting performance, reducing the need for replacements or repairs.
  • Variable Speed Control: Customize speed settings to match your specific application requirements.
  • Mounting Configurations: Choose from flange-mounted, foot-mounted, or face-mounted styles for optimal integration into your conveyor system.
  • Enhanced Sealing for Washdown Environments: Optional sealing configurations are available for environments requiring washdown and strict hygiene standards.
  • Custom Gear Ratios: Available upon request to fine-tune motor output for specific operational needs.

    • Key Features

    • Compact, Space-Saving Design

    • Maintenance-Free Sealed Gearbox

    • Variable Speed Control

    • Robust Construction

    • Versatile Mounting Options

    Documentation

    No items found.
    Specification Details
    Power Options 90V DC, 115V AC (single-phase), 230-460V AC (three-phase)
    Motor Type Right angle gear motor with high torque output
    Speed Range Adjustable speed to suit various conveyor applications
    Drive Mounting Compact, external drive with precise alignment
    Maintenance Sealed, maintenance-free bearings for reduced downtime
    Load Capacity Handles diverse conveyor system load requirements
    Compatibility Designed for integration with multiple conveyor systems
    Warranty 2-year unlimited hours, including bearings
